C7_a

Integrated Traffic Device

Features:

v   Composite design for various applications.

v   Support holder for Embedded, Antenna, Camera & Lens.

v   Negative Pressure design to avoid the oil and dust pollution.

v   Rotation Angle design to avoid the horizontal problem.



Applications:

v   Traffic speed management





Item Number

C7_a

C7_20_a

C7_D_a

Product’s Name

Integrated Traffic Device

Wavelength

NIR 850 nm

Light Drive Power(Plused)

600W

Illumination Source

Latest High Power Technology LEDs

Distance

100m / 30m (ANPR model)

Trigger Modes

A. Simple Strobe
B. Intelligent Strobe. (Trigger Width = Flash out width)
C. Continuous Combine Strobe

Min. Repeat Time

30us

Max. Pulse Width

Full Strobe 0.1-1.6ms/ Strobe+PWM 0.1-6ms

Trigger input

DC3.3V to 24V opto-isolated

Control/ Communication

RS485

Beam Angle

10

20

H40xV15

Operating Temperature (°C)

-20~+60 degree

Power Requirement

AC24V/ DC 24V @2A/ POE IEEE802.3a @60W

Weather Proof

IP66

Dimension

(L)245 x (W)306 x (H)232 mm

Net Weight

5 Kgs

Gross Weight

6.5 Kgs
