KJ3
Features:
v Super long range up to
300m.
v IP66 enclosure for outdoor
installation.
v Compact LED Light source.
v Ultra high power-low
urnning cost.
v Automatic Day/Night
switch.
Applications:
v Where light conditions are
less than optimal.
Item
Number | KJ3_10 | KJ3_20 | KJ3_30 | KJ3_D |
Product’s
Name | DC Illuminator | |||
Wavelength | Deep Far-Red 760nm | |||
Illumination
Source | Latest High Power Technology LEDs | |||
Distance | 220m | 150m | 90m | 120m |
Material | Aluminum | |||
Beam Angle (degree) | 10 | 20 | 30 | H40x15 |
Active Switch On | Controlled
by built-in photocell | |||
ICR
Switching | Trigger output: Provide DC12V drive
power | |||
Power
Consumption | 80W | |||
Power
Requirement | DC12~30V | |||
Operating
Temperature (°C) | -30~+60 degree (cold start at -40
degree) | |||
Operating
Humidity | 20%~90% RH | |||
Weather
Proof | IP66 | |||
Net
Weight | 3.2 Kgs | |||
Gross
Weight | 3.7 Kgs (5m cable included) | |||
