KP3

DC Illuminator

Features:

v   Super long range up to 300m.

v   IP66 enclosure for outdoor installation.

v   Compact LED Light source.

v   Ultra high power-low urnning cost.

v   Automatic Day/Night switch.



Applications:







Item Number

KP3_10

KP3_20

KP3_30

KP3_D

Product’s Name

DC Illuminator

Wavelength

810nm

Illumination Source

Latest High Power Technology LEDs

Distance

180m

120m

70m

120m

Material

Aluminum

Beam Angle (degree)

10

20

30

H40x15

Active Switch On

Controlled by built-in photocell
Trigger Input: DC3.3V to 24V opto-isolated

ICR Switching

Trigger output: Provide DC12V drive power

Power Consumption

80W

Power Requirement

DC12~30V

Operating Temperature (°C)

-30~+60 degree (cold start at -40 degree)

Operating Humidity

20%~90% RH

Weather Proof

IP66

Net Weight

3.2 Kgs

Gross Weight

3.7 Kgs (5m cable included)
