KR1

DC Illuminator

Features:

v   Super long range up to 300m.

v   IP66 enclosure for outdoor installation.

v   Compact LED Light source.

v   Ultra high power-low urnning cost.

v   Automatic Day/Night switch.



Applications:







Item Number

KR1_10

KR1_20

KR1_30

KR1_D

Product’s Name

DC Illuminator

Wavelength

Far-Red 730nm

Illumination Source

Latest High Power Technology LEDs

Distance

200m

150m

80m

120m

Material

Aluminum

Beam Angle (degree)

10

20

30

H40x15

Active Switch On

Controlled by built-in photocell
Trigger Input: DC3.3V to 24V opto-isolated

ICR Switching

Trigger output: Provide DC12V drive power

Power Consumption

50W

Power Requirement

DC12~30V

Operating Temperature (°C)

-20~+60 degree (cold start at -40 degree)

Operating Humidity

20%~90% RH

Weather Proof

IP66

Net Weight

2.0 Kgs

Gross Weight

2.5 Kgs (5m cable included)
