KW1
Features:
v Super long range up to 300m.
v IP66 enclosure for outdoor installation.
v Compact LED Light source.
v Ultra high power-low urnning cost.
v Automatic Day/Night switch.
Applications:
v Where light conditions are less than optimal.
Item Number | KW1_10 | KW1_20 | KW1_30 | KW1_D |
Product’s Name | DC Illuminator | |||
Wavelength | White, 4000K | |||
Illumination Source | Latest High Power Technology LEDs | |||
Distance | 80m | 60m | 35m | 50m |
Material | Aluminum | |||
Beam Angle (degree) | 10 | 20 | 30 | H40x15 |
Active Switch On | Controlled by built-in photocell | |||
ICR Switching | Trigger output: Provide DC12V drive power | |||
Power Consumption | 50W | |||
Power Requirement | DC12~30V | |||
Operating Temperature (°C) | -20~+60 degree (cold start at -40 degree) | |||
Operating Humidity | 20%~90% RH | |||
Weather Proof | IP66 | |||
Net Weight | 2.0 Kgs | |||
Gross Weight | 2.5 Kgs (5m cable included) | |||
