KY3
Features:
v Super long range up to 300m.
v IP66 enclosure for outdoor installation.
v Compact LED Light source.
v Ultra high power-low urnning cost.
v Automatic Day/Night switch.
Applications:
Item Number | KY3_10 | KY3_20 | KY3_30 | KY3_D | KY3_60 |
Product’s Name | DC Illuminator | ||||
Wavelength | White, 5600K | ||||
Illumination Source | Latest High Power Technology LEDs | ||||
Distance | 120m | 90m | 45m | 75m | 35m |
Material | Aluminum | ||||
Beam Angle (degree) | 10 | 20 | 30 | H40x15 | 60 |
Active Switch On | Controlled by built-in photocell | ||||
ICR Switching | Trigger output: Provide DC12V drive power | ||||
Power Consumption | 80W | ||||
Power Requirement | DC12~30V | ||||
Operating Temperature (°C) | -30~+60 degree (cold start at -40 degree) | ||||
Operating Humidity | 20%~90% RH | ||||
Weather Proof | IP66 | ||||
Net Weight | 3.2 Kgs | ||||
Gross Weight | 3.7 Kgs (5m cable included) | ||||
