SR1-N

Intelligent Traffic LED Strobe Illuminator

Features:

v   Compact with Integrated LED Light Source.

v   Auto detects the trigger width with flash duation.

v   Stack effect Design for more efficiency by reducing heat.

v   Extra long life with very low maintenance.

v   IP66 housing for outdoor installation.



Applications:

v   Face recognition behing windshield

v   Automatic number plate recognition

v   Weigh in motion

v   HOV (High Occupancy Vehicle)







Item Number

SR1_10-N

SR1_20-N

SR1_D-N

Product’s Name

Intelligent Traffic LED Strobe Illuminator

Wavelength

730 nm

Light Drive Power (Pulsed)

150 W

Illumination Source

Latest High Power Technology LEDs

Distance

15 to 20m (ANPR model)

Trigger Modes

1. Simple Mode (Strobe combine with continuous limit pulse)

2. Intelligent Mode (Trigger width = Flash width)

3. C.C.S (Continued Combine Strobe)

Max. Trigger Frequency

10 kHz

Max. Pulse Width

0.1~1.6ms

Trigger input opto isolated

DC3.3V to 24V opto-isolated

Beam Angle

10 degree

20 degree

H40xV15 degree

Control/ Communication

RS485 interface

Operating Temperature (°C)

-20~+60 degree (cold start at -40 degree)

Weather Proof

IP66

Power Requirement

DC 24V/ 1.5A
